DOWNLOAD Our latest version!

Click here to download Visuino 8.0.0.112

Click here to download PRO 8.0.0.112

Learn more about Visuino Professional version Here

What’s new?

Added Arduino UNO R4 WiFi support
Added Arduino UNO R4 Minima support
Added the option to send breaks, and have improved the RS485 support
Added initial support for QWIIC/STEMMA interfaces
Added proper pin mapping to all Serial and SPI interfaces, for boards that support mapping
Added Silicognition RP2040-Shim
Added Adafruit Metro RP2040
Added Unsigned Array components
Added Complex Math components
Improved CAN bus support
Added CAN bus shields support
Added CAN bus filter components
Added ESP32 CAN bus support
Arduino UNO R3 moved to pure text definition
Added support for sending Breaks over the Serial ports
Improved RS485 Serial support
Improved support for the Sending signal of the Serial ports
Added option to Disable any processor element
Improved Grove support
Added WakeUp by pins, and touch support for ESP32, ESP32 S2 and ESP32 S3
Added STM32 RTC support
Added option to Disable Value Source Elements

New Components:

Add Complex
Add Complex Value
Subtract Complex Value
Subtract From Complex Value
Multiply Complex By Analog Value
Multiply Analog By Complex Value
Divide Analog Value by Complex
Divide Complex by Complex Value
Divide Complex Value
Conjugate Complex
CAN bus Value
Binary To CAN bus
CAN bus To Binary
CAN bus Multi-Source Merger
CAN bus Multi Source
Repeat CAN bus
CAN bus On/Off Switch
CAN bus Toggle Switch
CAN bus Demux(Multiple Output channel Switch)
CAN bus Toggle Demux
CAN bus Mux(Multi channel Switch)
CAN bus Snapshot
CAN bus Array
Unsigned Array Delete Items
Unsigned Array Insert Items
Unsigned Array Replace Items At Index
Unsigned Array Snapshot
Remember Unsigned Array
Step/Iterate Unsigned Array Items
Get Unsigned Array Item At Index
Unsigned Array Value
Unsigned Array Replace
Unsigned To Unsigned Array
Unsigned Array Change Only
Unsigned Array Mux(Multi channel Switch)
Unsigned Array On/Off Switch
Unsigned Array Toggle Switch
Unsigned Array Demux(Multiple Output channel Switch)
Repeat Unsigned Array
Added Generic TM1637 7 Segment Display 6 Digits Module component
Added DIY More TM1637 7 Segment Display 6 Digits Module component
Improved Detect Edge(Digital to Clock) component implementation
Added Arduino 4 Relays Shield
Added HiLetgo 4 Relays Shield
Added Generic Multi Function Shield
Added Unsigned Array Package/Structure elements
Improved M5Stack CoreS3 support
Improved 74HC595 Shift Register support
Added 74HC595 Shift Register 8 Digits 7 Segment Display support
Added Complex To Complex Array
Analog Array Change Only
Analog Array Multi Source
Complex Array Change Only
Complex Array Multi Source
Analog Array Mux(Multi channel Switch)
Analog Array On/Off Switch
Analog Array Toggle Switch
Analog Array Toggle Demux
Analog Array Demux(Multiple Output channel Switch)
Repeat Analog Array
Complex Array Mux(Multi channel Switch)
Complex Array On/Off Switch
Complex Array Toggle Switch
Complex Array Toggle Demux
Complex Array Demux(Multiple Output channel Switch)
Repeat Complex Array components
Added 64 bit Unsigned filter components
Deprecated the old Dynamic 7 Segment Display components
Added Improved Dynamic 7 Segment Display support
Improved Digispark support
Redesigned array and binary data components to improve performance, and reduce memory usage
Improved On/Off delay component
Improved M5 Stack ATOM Matrix support
Improved Waveshare RP2040-Matrix RGB 5×5 Matrix support
Improved bpi:bit (ESP32) support
Added STM32 Generic STM32L031K6 support
Added STM32 Nucleo-32 STM32L031K6 support
Improved SubDiagrams support
This version also for first time officially includes signed installer
